Name

Banner Unit MK-764

Applicable unit

Trimmer Unit TU-510

Type

Unit structure mounted in Trimmer Unit TU-510

Function

Banner paper conveyance and reverse

Conveyance section: Corrects a banner paper skew before trimming or creasing.

Reverse section: Reverse-conveys banner paper to the post-processing device after trimming or creasing.

Paper size

Conforms to Trimmer Unit TU-510

Paper weight

Conforms to Trimmer Unit TU-510

Dimensions

Conveyance section: 352.4 mm (W) e 589.5 mm (D) e 516 mm (H) / 13.87" (W) e 23.21" (D) e 20.32" (H)

Reverse section: 770 mm (W) e 554.8 mm (D) e 77 mm (H) / 30.32" (W) e 21.84" (D) e 3.03" (H)

Weight

Approx. 34.8 kg / 41.89 lb (Conveyance section: 26.0 kg / 57.32 lb, Reverse section: 8.8 kg / 19.40 lb)

Power

Supplied from Trimmer Unit TU-510

Maximum power consumption

50 W
