Features

The art of performance — high performance 9-color archival pigment for high-volume photographic printing environments
Remarkable productivity — PrecisionCore MicroTFP printhead utilizing 8,000 nozzles, for print speeds up to twice as fast as our previous generation
Industry-standard workflow software — ONYX RIPcenter software incorporates an Adobe PostScript engine to maximize workflow productivity; supports leading photo, fine art and signage media
Low cost of operation — high-capacity 700 mL ink cartridges, along with more efficient ink usage, allows for a low cost per print
Outstanding print quality — Epson UltraChrome PRO archival ink technology produces exceptional color prints that last up to 200 years1, along with four levels of gray for accurate transitions with very low grain, even at the fastest print modes
Superior workflow features — standard gigabit Ethernet and Hi-Speed USB, along with an internal 320GB print server, allow for exceptional networking performance for multiple workstations, a built-in Web page for job and file management and job accounting capabilities
UltraChrome® Pro Inks

Next Generation Pigment Ink Technology – Introducing all new pigments for outstanding color performance and Improved Resin Encapsulation Technology for superior gloss uniformity
Improved Black Density – Photo Black pigment 1.5 times denser than the previous generation ink set, along with significant improvement to overall contrast ratio and optical clarity
Significant Print Permanence Improvements – Featuring completely reformulated pigment technology for improved print permanence, and up to twice the overall print permanence versus our previous generation ink set
Extreme Color Balance – 4 levels of black, featuring an all-new dark gray for rendering superb gray balance through the entire tonal range of B&W and color prints at any production speed
PrecisionCore® microTFP Printhead
Design for Production – 2.6 inch tall printhead with 800 nozzles per color, 8000 high performance nozzles in all
Robust Engineering – Single head configuration designed for maximum quality and reliability in demanding high-speed environments
Epson Precision Dot – Delivers best-in-class continuous tone image quality at production level print speeds
Printer Applications
Ultra-Fast Drafts – Print at up to 1,135 sq ft/hour (1 pass) on plain paper when speed is the critical factor
High-Speed Poster Printing – For high-speed production on various coated media types, the 381 sq ft/hour (4 pass) and 251 sq ft/hr (6 pass) modes provide highly sellable output
Indoor Display Graphics – The 273 sq ft/hour mode (6 pass) on semigloss or glossy media provides eye-catching photographic quality even up close
On-demand Photo & Fine Art – Start with 194 sq ft/hour (8 pass) or move up in quality to 96 sq ft/hour (16 pass) for best-in class fine art production printing. Perfect for use with Epson Signature Worthy Canvas, Fine Art and Photo media
Exhibition Quality Prints – Combine maximum quality 63 sq ft/hour (24 pass) with the highest quality Epson Legacy photo media for prints worthy of the world's most exclusive galleries and exhibitions

Specifications

Print:
Printing Technology:
Advanced PrecisionCore MicroTFP Print Head
10-channel, piezo inkjet print head
Minimum Ink Droplet Size:
Enhanced Variable Droplet Technology as small as 3.5 picoliters
Maximum Print Resolution:
2400 x 1200 dpi; 1200 x 1200 dpi; 1200 x 600 dpi; 600 x 600 dpi; 600 x 300 dpi
Print Speed:
16" x 20" prints from 1:47 to 3:17 Production is 2:092
20" x 30" prints from 2:55 to 5:33 Production is 3:402
Nozzle Configuration:
Color and Monochrome; 800 nozzles x 10 channels
Ink:
Ink Type:
Epson UltraChrome PRO pigment inks
Printer is designed for use with Epson cartridges only, not third-party cartridges or ink.
Ink Palette:
C, LC, VM, VLM, Y, LGY, GY, DGY, PK, MK
Ink Configuration:
10-ink, 9-color
Replacement Ink:
Photo Black T800100
Cyan T800200
Vivid Magenta T800300
Yellow T800400
Light Cyan T800500
Vivid Light Magenta T800600
Dark Gray T800700
Matte Black T800800
Gray T800900
Light Gray T800000
Fade Resistance / Print Longevity:
UltraChrome PRO, our next-generation pigment ink technology, is independently rated by Wilhelm Research for up to 200 years for color prints and up to 400 years for black-and-white prints1
General:
Operating Systems:
Printer Driver:
Apple macOS® 10.13.x-10.12.x, OS X®: 10.11x-10.7x
Microsoft® Windows®: 10, 8.1, 7 (32-bit, 64-bit)

Onyx RIPCenter Supported:
Microsoft® Windows®: 10, 8.1, 7 Professional (64-bit)
RAM: 8GB minimum (4GB/ core recommended)
1 dedicated USB port for security key

Temperature:
Operating: 50° to 95°F (10° to 35°C)
Operating Recommended: 65° to 75°F (18° to 24°C)
Storage: -4° to 104°F (-20° to 40°C)
Humidity:
Operating: 20 to 80% (no condensation)
Operating Recommended: 40 to 60% (no condensation)
Storage: 5 to 85% (no condensation)
Sound Level:
Sound Pressure Level: Less than 51.1 dB(A)
Sound Power Level: approx. 65.3 dB(A)
Dimensions:
Basket Open: 74.0” x 38.6" x 45.1" (1879 x 976 x 1145 mm)
Weight:
278 lbs (126 kg)
Safety Approvals:
Safety Standards: UL605950-01, CAN/CSA C22.2 No. 60950-1 EMC FCC part 15 subpart B class A, CAN/CSA-CEI/IEC CISPR22 class A, AS/NZS CISPR 22 class A
Country of Origin:
China
Warranty:
Standard one-year on-site next business day service with toll-free phone support Monday thru Friday.
Optional Epson SureColor P-Series Extended service plans available for purchase.
Ink Supply System:
Ink Supply Fill Volume:
Initial cartridge fill volume: 110 ml x 10 total colors (used for initial fill at setup)
Cartridge fill volume: 700 ml each x 10 colors total
Ink Shelf Life:
2 years from printed production date or 6 months after open
Printable Area and Accuracy:
Maximum Paper Width:
44"
Minimum Cut-sheet Size:
8.5" x 11"
Minimum recommended cut-sheet: 13" x 19"
Minimum Paper Width:
10"
Maximum Printable Width:
44” in BorderFree print mode
43.75” in standard print mode
Line Accuracy:
+/- 0.2% of specified length
+/- .26mm minimum
Maximum Printable Length:
Cut-sheet: 80"
Roll: 590.55"5
As allowed by the Epson MAC and PC printer driver. Application, version of application and Operating System version may limit maximum length.
Sheet Media Handling:
Sheet Loading:
Top-loading if less than .5mm thick
Thickness:
0.8mm to 1.5mm
Single Sheet, Top-loading:
Up to 44" wide
BorderFree Print Widths:
Left and right borderless "bleed" printing for the following roll media widths:
10", 11.8", 13", 16", 17", 20", 23", 24", 28.86", 29", 33.11", 36", 40.55", 44"
Left/Right Margins:
3mm each side; 6mm or 0.24" total
Top/Bottom Margins:
3mm / 15mm (0.12"/0.59")
15mm / 15mm (with centering)
Printer Details:
Printer Language:
Epson Professional Photographic Drivers standard; optional internal Adobe® Postscript® 3™ print server1
Interfaces:
USB 2.0 (1 port)
1000Base-T Ethernet (1 port)
Power:
Rated Voltage:
AC 110 – 240 V
Rated Frequency:
50 – 60 Hz
Power Consumption:
Printing: approx. 95 W
Sleep Mode: approx. 2.8 W (1000 BaseT Ethernet in Standby Mode)
Power Off: less than 0.5 W ENERGY STAR® qualified
Rated Current:
5 A
