Features

UltraChrome® Pro Inks
Next Generation Pigment Ink Technology — Introducing all new pigments for outstanding color performance and Improved Resin Encapsulation Technology for superior gloss uniformity
Improved Black Density — Photo Black pigment 1.5 times denser than the previous generation ink set, along with significant improvement to overall contrast ratio and optical clarity
Significant Print Permanence Improvements — Featuring completely reformulated pigment technology for improved print permanence, and up to twice the overall print permanence versus our previous generation ink set1
Extreme Color Balance — 4 levels of black, featuring an all-new dark gray for rendering superb gray balance through the entire tonal range of B&W and color prints at any production speed
PrecisionCore® microTFP Printhead
Design for Production — 2.6 inch tall printhead with 800 nozzles per color, 8000 high performance nozzles in all
Robust Engineering — Single head configuration designed for maximum quality and reliability in demanding high-speed environments
Epson Precision Dot — Delivers best-in-class continuous tone image quality at production level print speeds
Printer Applications2
Ultra-Fast Drafts — Print at up to 1,311 sq ft/hour (1 pass) on plain paper when speed is the critical factor
High-Speed Poster Printing — For high-speed production on various coated media types, the 411 sq ft/hour (4 pass) and 273 sq ft/hr (6 pass) modes provide highly sellable output
Indoor Display Graphics — The 273 sq ft/hour mode (6 pass) on semigloss or glossy media provides eye-catching photographic quality even up close
On-demand Photo & Fine Art — Start with 209 sq ft/hour (8 pass) or move up in quality to 104 sq ft/hour (16 pass) for best-in class fine art production printing. Perfect for use with Epson Signature Worthy Canvas, Fine Art and Photo media
Exhibition Quality Prints — Combine maximum quality 68 sq ft/hour (24 pass) with the highest quality Epson Legacy photo media for prints worthy of the world's most exclusive galleries and exhibitions

Specifications

Print:
Printing Technology:
Advanced PrecisionCore MicroTFP Print Head
10-channel, piezo inkjet print head
Minimum Ink Droplet Size:
Enhanced Variable Droplet Technology as small as 3.5 picoliters
Maximum Print Resolution:
2400 x 1200 dpi; 1200 x 1200 dpi; 1200 x 600 dpi; 600 x 600 dpi; 600 x 300 dpi
Print Speed:
16" x 20" prints from 1:47 to 3:17 Production is 2:092
20" x 30" prints from 2:55 to 5:33 Production is 3:402
40" x 60" prints from 8:33 to 16:30 Production is 10:522
Nozzle Configuration:
Color and Monochrome; 800 nozzles x 10 channels
Ink:
Ink Type:
Epson UltraChrome PRO pigment inks
Printer is designed for use with Epson cartridges only, not third-party cartridges or ink.
Ink Palette:
C, LC, VM, VLM, Y, LGY, GY, DGY, PK, MK
Ink Configuration:
10-ink, 9-color
Replacement Ink:
Photo Black T800100
Cyan T800200
Vivid Magenta T800300
Yellow T800400
Light Cyan T800500
Vivid Light Magenta T800600
Dark Gray T800700
Matte Black T800800
Gray T800900
Light Gray T800000
Fade Resistance / Print Longevity:
UltraChrome PRO, our next-generation pigment ink technology, is independently rated by Wilhelm Research for up to 200 years for color prints and up to 400 years for black-and-white prints1
General:
Operating Systems:
Apple macOS® 10.13.x-10.12.x, OS X®: 10.11x-10.7x6
Microsoft® Windows®: 10, 8.1, 7 (32-bit, 64-bit)6
Temperature:
Operating: 50° to 95°F (10° to 35°C)
Operating Recommended: 65° to 75°F (18° to 24°C)
Storage: -4° to 104°F (-20° to 40°C)
Humidity:
Operating: 20 to 80% (no condensation)
Operating Recommended: 40 to 60% (no condensation)
Storage: 5 to 85% (no condensation)
Sound Level:
Sound Pressure Level: Less than 51.1 dB(A)
Sound Power Level: approx. 65.3 dB(A)
Dimensions:
Basket Open: 95.1" x 38.4" x 45.1" (2415 x 980 x 1168 mm)
Weight:
377 lbs (171 kg)
Safety Approvals:
Safety Standards: UL605950-01, CAN/CSA C22.2 No. 60950-1 EMC FCC part 15 subpart B class A, CAN/CSA-CEI/IEC CISPR22 class A, AS/NZS CISPR 22 class A
Country of Origin:
China
Warranty:
Standard one-year on-site next business day service with toll-free phone support Monday thru Friday.
Optional Epson SureColor P-Series Extended service plans available for purchase.
Ink Supply System:
Ink Supply Fill Volume:
Initial cartridge fill volume: 110 ml x 10 total colors (used for initial fill at setup)
Cartridge fill volume: 700 ml each x 10 colors total
Ink Shelf Life:
2 years from printed production date or 6 months after open
Printable Area and Accuracy:
Maximum Paper Width:
64"
Minimum Cut-sheet Size:
8.5" x 11"
Minimum recommended cut-sheet: 13" x 19"
Minimum Paper Width:
10"
Maximum Printable Width:
64” in BorderFree print mode
63.75” in standard print mode
Line Accuracy:
+/- 0.2% of specified length
+/- .26mm minimum
Maximum Printable Length:
Cut-sheet: 80"
Roll: 590.55"
As allowed by the Epson MAC and PC printer driver. Application, version of application and Operating System version may limit maximum length.
Sheet Media Handling:
Sheet Loading:
Top-loading if less than .5mm thick
Thickness:
0.8mm to 1.5mm
Single Sheet, Top-loading:
Up to 44" wide
BorderFree Print Widths:
Left and right borderless "bleed" printing on sheet and roll for the following media widths:
10", 11.8", 12.95", 16", 17", 20", 23", 24", 28.86", 29", 33.11", 36", 40.55”, 44”, 50” 54” and 60”
Left/Right Margins:
3mm each side; 6mm or 0.24" total
Top/Bottom Margins:
3mm / 15mm (0.12"/0.59")
15mm / 15mm (with centering)
Printer Details:
Printer Language:
Epson Professional Photographic Drivers standard; optional internal Adobe® Postscript® 3™ print server1
Interfaces:
USB 2.0 (1 port)
1000Base-T Ethernet (1 port)
Power:
Rated Voltage:
AC 110 – 240 V
Power Consumption:
Printing: approx. 95 W
Sleep Mode: approx. 2.8 W (1000 BaseT Ethernet in Standby Mode)
Power Off: less than 0.5 W ENERGY STAR® qualified
Rated Current:
5 A
